International famous Cummins Engine + FASTRE 16-gear transmission adopted, which is reliable and stable in technology, so that customers can use under multiple road conditions.The economy is greatly improved; and 16-gear transmission is adopted to match PTO to the extreme under diferent speeds. Moreover, the product quality has been tested by the market, with the high-quality characteristics of mature technology and durability. Safety and reliability are the frst design elements in the bodywork design stage of the vehicle and key confgurations such as bodywork and axle are strengthened. The drive axle has adopted disc brake, which can greatly improve the braking efect; and the hydraulic retarder can be selected to reduce the braking pressure on downhill section and provide higher guarantee for driving safety; as for bodywork, the thickness of the frame and the size of the inner liner panel are increased to improve the bearing capacity of the vehicle.
Drive Type: 6×4
Kerb Mass: 9750 kg
GVW: 60000 kg
Max. Speed: 100 km/h
Min. Turning Diameter: 17 m
Grade Ability: ≥31%
Fuel Tank: 700 L
Dimension: 7210×2500×3910 mm
Wheelbase: 3300+1350 mm
Min. Clearance: 280 mm
Approach Angle: 20°
Departure Angle: 31°
Cabin Model: XG1-H
Left/Right Driving: LHD
AC: Standard
Person Allowed in: 2
Engine Model: ISZ460 51
Emission Standard: EUR V
Displacement: 13 L
Output Power: 338 KW
Max Torque Speed: 2330 km/h
Transmission Model: C16JSDQXL240TA
PTO: QH50
Front Axle Model: 7.5T
Rear Axle Model: 16T
Main Reducer Ratio: 4.625/4.111
Rim: 24.5×8.25
Tire: 11R24.5
