A-36 Carbon Steel Construction
Double-welded Design
Pitched Roof (Approx. 10 Degrees)
Sloped Cone (Approx. 20 Degrees)
2’-0” Cone Discharge Height
Angle Iron Legs & X-Bracing
20” Non-pressurized Manhole
2” NPT Inlet, Outlet, & Vent Couplings
Outside Ladder with OSHA Compliant Fall Arrest Cable System
Sandblast, Prime, and Paint
Standard Colors:
RAL 7038 Gray, RAL 9010 White, RAL 1001 Tan, RAL 1032 Yellow
RAL 7038 Gray, RAL 9010 White, RAL 1001 Tan, RAL 1032 Yellow
