With new generation Yanmar engine and newly optimized fuel injection system, XE60DA has strong power and low fuel consumption. The cross-grade main pump is perfectly matched with the engine power. The oil pipe is arranged on both sides of the cylinder to prevent the cylinder pipe from being damaged due to excessive movement. The three intelligent modes of E/P/B control can easily cope with crushing, light load and heavy load working conditions. With automatic idle control technology, it realizes more than 10% reduction of fuel consumption in operation. With short tail and short slewing radius, it can realize complex operation together with upper structure slewing.
Operating weight: 6010 Kg
Rated power: 36.2 kW/rpm
Engine model: Yanmr 4TNV94L
Bucket capacity: 0.23 m³
Emission standard: National Stage Ⅲ
Maximum torque/speed: 207.4/1000 N.m
Displacement: 3.054 L
Travel speed: 4.2/2.4 km/h
Swing speed: 10 r/min
Bucket digging force: 48.3 kN
Arm digging force: 32.5 kN
